Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 414
ere to the sieve, and, bycapillary entrainment, willpass through its meshesto the top surface of thehood. The water or oil thusdeposited flows through thedrainage tubes D, to thecollecting-chamber, C. Impact with the conical surface changes the form of thesteam-current to that of an annular sheet… … -Conical Top of Hood-.-SieveCentering Wings Cylindrical Wat!of Hood--. ■Trapping Sheet Secondary Sep-aration by Rever-sal of Current Annular Spacebetween Trapping-sheet and Exter-nal Shell ■■ Drain Outlet- Fig. 382.- Giass-water-...-<?age Outlet-Tube -Sweet Mesh Vertical Steam Sep-arator. 394…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
