Water Column Strainer-*-- ■Alloy Expansion Tube Fig. 395.—Kieley Expansion Intermittent-Discharge Steam Trap Draining Radia-tion. When T Fills With Water And Cools, It Contracts And Draws In H And P.V Is Then Opened By Upward Thrust Of S Against L. When Steam Enters, T Ex-pands And Pushes Out H And… … Fig. 396.—Strong Vacuum Trap Installed For Draining Separator In Condensing-Engine Exhaust-Line. When F Rises, V Closes And P Opens, Permitting Live SteamOr Atmospheric Air Pressure To Discharge Accumulated Water W, Sec. 4SS] STEAM TRAPS 405 Steam Traps May Be Classified According To The…
