Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 426
Installed For Draining Closed Feed WaterHeater. When Steam Enters Casing Of Trap, T Expands And Closes V. When WaterAccumulates In Inlet Pipe, T Contracts and Opens V. Water Enters Casing C OfTrap And Passes Out Through O. 488. The Main Operating Principle Of Return Steam-Traps (Fig. 399) is… … Hmae- Fig. 398.—Arrangement Of Tilting-Bucket-Float Intermittent-Discharge High-Pressure Steam Traps For Draining Live-Steam Separators And Reheating-Coils OfTwo Cross-Compound Engines. the trap is intended to discharge. This is accomplished by-admitting boiler-steam to the trap. With the…
Steam power plants · Pumping machinery
