Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 160
Fig. 103. Automatic Eeltef Valve Used in Gorton System ofVacuum Steam Heating. Main, t/team … Ti^. 104. Connections at Boiler in Gorton System of VacuumSteam Heating. 134 HEATING AND VENTILATION lines similar to those of the K-M-C and Tranesystems. With it the air is exhausted to theatmosphere through an air-trap. A small steampipe connected directly to the trap from theboiler, acts as an…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
