Exhaust Port-■■ Admission Port- Fig. 74.—Piston Pi At End Of InboardStroke And On Point Of Reversal. PistonPz Approaching End Of Head-End Stroke. Admission Port—^ Exhaust Port—.Center Lines of ^¥Piston Rods-. … Center Lines ofValve Stems- ■ • Exhaust Port—- Admission Port— Fig. 75.—Piston P2 At End Of Head-End Stroke And On Point Of Reversal.Piston Pi Approaching End Of Head-EndStroke. Piston P2 (Fig. 75) has completed its return stroke. Coincidentally,piston Pi has traveled far enough on its return…
