Steam turbine engines : their construction, care and operation (1910)
Swingle, Calvin F. (Calvin Franklin), b. 1846 · Chicago : Frederick J. Drake · leaf 88
which carry the blades are pressed onthe shaft. Fig. 282 illustrates the blades as they appearwhen fitted on to the rotor. The shroud ring protectingthe tips of the blades is also shown in place. Fig. 283shows another view of the blade construction. This is ahalf-ring of blades inserted in the… … Fig. 281 rotor of allis-cn almers steam turbine iSltuin JjiKjiiittrmg
Steam-engines -- Design and construction · Steam-turbines -- Handbooks, manuals, etc
