i5 16 Vs 7 16 y2 91 i) Fig. 53. Proportions of Rivets in Inche3From American Bridge Company 58 STEEL CONSTRUCTION that the diameter at the outside is greater than at the inside ofthe plate. The sizes of rivet heads are shown in Fig. 53. Theconventional signs for riveting are given in the handbooks.… … Fig. 54. 100-Ton Hydraulic Riveter, 120-ineh GapCourtesy Mackintosh, Hemphill & Company turns. A flattened rivet should be used in preference to a counter-sunk rivet; but when a smooth surface is to be obtained, the headmust be countersunk and chipped flush with the plate. Driving. Before…
