than the nominal sizeof the rivet for when the rivet is heated, it expands somewhat,making it necessary to have the larger size hole. The driving ofthe rivet must be done in such a way as to upset the metal of theshank so that it fills the rivet hole solidly, even to the extent offilling out any… … Fig. 56. Rivet Ready for DrivingCourtesy Vulcan Engineering Sales Company Riveting Machines in Shop. In the shop, rivets are driven withan hydraulic riveter, Fig. 54, or a pneumatic riveter, Fig. 55. The
