intel. In addition to the weight of the brickwork, the lintel may haveto support the end of a girder as in case d, or it may have to supportsome floor area as in case e. STEEL CONSTRICTION 117 Case/shews a section through a wall in which the outer courseof brickwork is supported by a lintel and the… … Fig. SS. Types of Lintels EXAMPLES FOR PRACTICE 1. Design lintel for case a, span 4 feet, wall thickness 9 inches.Use 2 Ls. The horizontal legs of the angles should be 3| or 4 incheswide to support the brickwork properly. See Table II for formulafor bending moment for this condition of loading. 2.…
