Fig. 174. Diagram of TwoHorizontal Panctsof Triangular Framing Problem Assume four panels similar to thoseshown in Fig. 174. Let H equal 16 feet;L„ L2, L3, and L4 equal 20 feet; and Wequal 36,000 pounds. Compute the stressesin the diagonals. Two or More Vertical Panels.Two or more panels may be…
