Stereotomy : Problems in stone cutting. In four classes. I. Plane-sided structures. II. Structures containing developable surfaces. III. Structrues containing warped surfaces. IV. Structures containing double-curved surfaces. For students of engineering and architecture (1875)

Warren, S. Edward (Samuel Edward), 1831-1909 · New York : J. Wiley and son · leaf 25

An illustration from Stereotomy : Problems in stone cutting. In four classes. I. Plane-sided structures. II. Structures containing developable surfaces. III. Structrues containing warped surfaces. IV. Structures containing double-curved surfaces. For students of engineering and architecture, 1875, leaf 25
the plates of this volume. 9. In order to secure a brief, yet comprehensive exhibition ofthe elements of stone-cutting, that is, one representing everyimportant class of structures, and form of surface, they maybe classified as in the General Table, the frontispiece. CLASS I. Plane-Sided…

Stereotomy

Internet Archive · UNC Libraries · Public Domain Mark 1.0. Free to use for anything.
