Stereotomy : Problems in stone cutting. In four classes. I. Plane-sided structures. II. Structures containing developable surfaces. III. Structrues containing warped surfaces. IV. Structures containing double-curved surfaces. For students of engineering and architecture (1875)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York : J. Wiley and son · leaf 25
Kg. l- Fig. 2. 10. First. Fig. 1. represents the first steps in forming aplane upon a wholly unwrought block. Having two straight-edges, AB and CD, of equal width, ledges, as m n and p q, arecut on opposite edges of the stone, until the tops of thestraight-edges placed on them, as shown, are found…
Stereotomy
