NTILATING OF SHIPS. Fig. 7 is a diagram of a number of radiators fed on the one-pipe system, the radiators being bridged across a certainlength of pipe, but, as will be noticed, two radiators are fedfrom one bridge, and in this case the connection to the balancetank is separate. Fig. 6 shows the… … fIG. 7. DISTRIBUTION OF LOW-PRESSURE HOT WATER ON THE ONE-PIPE SYSTEM. highest radiator, connection being made from the hot-watertank to the balance tank above; and the distributing pipescommencing from the hot-water tank and returning to thewater-jacket of the engine, and thence to the heating…
