Cold storage, heating and ventilating on board ship (1911)
Walker, Sydney Ferris · New York : Van Nostrand · leaf 229
EU —J … ^Exhaust steam ValYe .Humidifier Valyegteamjnlet ValveHumidi&er pipe FIG. 59.—tween deck type thermotank supplying air. from below then passing up through the fan, thence by theside of the air pipes and out through the mushroom valve atthe top. Figs. 59 and 6o show a between-deck apparatus.…
Ships -- Heating and ventilation · Cold storage on shipboard
