Steam engines, a thorough and practical presentation of modern steam engine practice (1920)
Ludy, Llewellyn V., 1875-, American Technical Society · Chicago, American technical society · leaf 144
elocity, which is imparted tothe water. The whole mixture of water,steam, and vapor passes at high velocitythrough the conical chamber E to the pumpcylinder F, where it is forced into the pipeG. The spray cone is adjusted by means ofthe stem which passes through the stuffingbox at the top of the… … Fig. 78. LongUodinal Section of Independent Jet Condenser and Pump
Steam-engines
