Fig. 21. The fly shuttle. thus great textile mills could use the labor-saving machines which had meanwhilebeen invented. In modern factories, the same principlesare used as in the early spinning wheels … Fig. 22. Card of Jacquard loom. through eyes, H, in needles, F, and theneedles, F, are pushed to the left by springs,G, against the surface of cards which lieone by one vertically against the right sideof the revolving cylinder, I. When a cardcomes into place, at the side of the cylinder,the…
Textile fabrics
