best kind in use. Fig. 145 illustratesa hinge that overcomes this objection. Type 3. The type of surface illustrated in Fig. 146 is well suited togood sized surfaces on two-seater airplanes. The construction is verysimple and strong. Although the ultimate strength of this design isgiven in Table… … 3azec/ )Or3 3u/des Fig. 144. Elevator Hinge on Curtiss Kirkham 18-T 217 Control Surfaces Art. 147 ribs may be decreased by using 3/32 in. 3-ply spruce lightened by cir-cular holes. The secondary spar is a 1/2 in. spruce rod. A strip of.065 in. gage aluminum forms the trailing edge, with bent ash…
