truts is zero. The deflections desired are those measured to thecurve of the funicular polygon from a line intersecting that curve at thecabane strut point and parallel to the tangent at the center line. In all of this work great care must be used to multiply the ordinatesmeasured from the drawing… … F/o. ii^Moment or /ne/?t//i C(/&i/e 3 a
