Structural analysis and design of airplanes (1920)
United States. Army. Air Corps · [Washington] · leaf 294
Fig. 179. Deflection of a Cantilever Beam Since it is usually more convenient to compute the values of M/lthan to obtain them graphically, the M/l curves may be plotted fromcalculated values. The scale, s, used in plotting this curve equals thevertical scale for Fig. 176 1 in. = mnpq2h = s. The…
Airplanes
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
