The student's instructor in drawing and working : the five orders of architecture : fully explaining the best methods for striking regular and quirked mouldings, for diminishing and glueing of columns and capitals, for finding the true diameter of an order to any given height, for striking the ionic volute, circular or elliptical, with finished examples, on a large scale, of the orders, their planceers, etc. and some designs for door-cases (1837)

Nicholson, Peter, 1765-1844 · New York : Office of the Railroad Journal · leaf 89

An illustration from The student's instructor in drawing and working : the five orders of architecture : fully explaining the best methods for striking regular and quirked mouldings, for diminishing and glueing of columns and capitals, for finding the true diameter of an order to any given height, for striking the ionic volute, circular or elliptical, with finished examples, on a large scale, of the orders, their planceers, etc. and some designs for door-cases, 1837, leaf 89
MODERNPlate IONIC. 25. … 31 PLATE XXV. The Ionic order with modillions, and an angular capital; the measures of the partsare accurately figured ; Fig, 1. is a section of the capital through the middle of the aba-cus, in order to show the projection of the mouldings. TO DRAW THE IONJC ORDER TO A GIVEN HEIGHT. For the Column…

Architecture

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
