t of the shuttles, the directionof movement being given. Occasionally wefting plans containing four or five dif- 160 TAPPET AND DOBBY LOOMS ferent colours in which the order of the colours is not sym-metrical may be woven in this loom. This is accom-plished by employing more than one shuttle on… … Position of Shuttles at Start. Movement. Shuttle. No . of Pick Forward w 32 Forward L 6 Forward X 32 Forward M 6 Backward X 32 Backward L rt Backward W 32 Backward D 6 X denotes N o. 2 white weft. only, as the dark grey is more than one box from the whitewhich precedes it. If two shuttles are…
