Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving (1888)
Posselt, Emanuel Anthony, 1858- · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 166
Fig. 770. removed in Fig. 770.) Mounted on the frame, or the attachments thereof, on opposite sides ofthe cutter, are tension-regulating rollers J K. Secured to the frame, and at the rear end, are trans-versely extending beams d e, around which the fabric to be cut is passed from the roller D to… … Fig. 771. roller adjusted by means of weighted levers P, which are pivoted to the frame A, and carryrollers Q, which are in contact with the peripheries of the heads of roller M. Supported on the base of the machine, or on the floor of the apartment, is a fan or blower, R,the pipe 5 whereof leads…
Textile design · Textile fabrics
