Technology of textile design : a practical treatise on the construction and application of weaves for all textile fabrics and the analysis of cloth : containing also an appendix describing all the latest methods and improvements in designing and manufacturing : for the use of students, operatives, overseers, designers, mill managers, commission merchants and manufacturers (1905)
Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia : E.A. Posselt ; London : Sampson Low, Marston, and Co., Ltd. · leaf 212
ts a side elevation of part of a loom for weaving double pile fabrics. The drawing also illustrates one of the " knife carriages " with its actuating mechanism, and part of the sharpening mechanism adjacent to it with a part of its actuating mechanism. Fig. 866 is a front view of part of the loom.… … Fig. 866. Fig. 867. Fig. 868 is, partly, a sectional front-view of a pair of the sharpening-rollers mounted in their frame with a portion of the velvet rail or cutting bar. Fig. 869 is a top-view of the transversely grooved guide-plate or race-bar in which the knife-carriages are reciprocated, and…
Textile design · Textile industry · Weaving
Internet Archive · Getty Research Institute · Public domain (published before 1931). Free to use for anything.
