Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics (1889)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 184

An illustration from Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics, 1889, leaf 184 — Fig. 822. Fig. 821. Each wire a thereupon enters beneath a number of warp-threads and raises themslightly above the plane of the fabric. A shuttle is then shot through, after which the body-warp 4 rises and the pile-warp i descends, as shown in Diagram II of Fig. 822. The pile-warp 2 rises and a…

Textile fabrics

Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
