Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics (1889)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 209

An illustration from Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics, 1889, leaf 209 — Fig. 873. Fig. 874. the tubing and fastened tight at any point thereon by a set-screw. By this arrangement therubber tubing acts as an elastic cushion for the stopper-rod and in turn for the knife-carriage.The movable metal band also permits of lateral adjustment of the stopper-rod, thereby…

Textile fabrics

Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
