Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing (1890)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, S. Low, Marston · leaf 137

An illustration from Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing, 1890, leaf 137
Fig. 616. Fig. 617. Fig. 618. The web U is ornamented by means of threads c, which pass from spools (not shown)mounted on the loom through the guides and thence respectively through the eyes of the needlesd m and into the web. Guards m2 are employed to prevent the needles from being sprung or drawn…

Textile fabrics
