Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 296

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 296
idly to a carriage capable of beingmoved in the direction of E F, which is the longi-tudinal axis of M and passes through A. Conse-quently, if the boring bar is rotated on its centersand the work fed gradually, in the ordinary way,along axis E F, the cutting tool, at each revolution,describes a…

Mechanical movements
