Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing (1890)
Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, S. Low, Marston · leaf 188
ofharness (indicated at the right-hand side). Diagram Fig. 808 illustrates the section of a fabric interlaced on weave Fig. 806. Bothground warp-threads, as working at the right and left, are indicated by dotted lines. The pile-warp indicated in full black is shown in the terry and velvet effect… … Fig. 811. Each pile warp-thread is drawn on a separate harness, as shown in Fig. 810. Diagram Fig. 811illustrates the method of operation in weaving a fabric with the weave just given. 2 picksground B, C, E, F; 1 pick for inserting wire A, D. In pick A the harness f raises warp-thread3 ; in pick D…
Textile fabrics
