Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing (1890)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, S. Low, Marston · leaf 192

An illustration from Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing, 1890, leaf 192
. In diagrams I to X in Fig. 822 are represented the positions which the threads assume ateach stage of the formation of the fabric. Two pile-warps may be used, which are indicated respectively by I and 2. The body-warps3 and 4 of the fabric are brought from a separate beam. To form a row of loops… … VI

Textile fabrics
