Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing (1890)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, S. Low, Marston · leaf 215

An illustration from Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing, 1890, leaf 215
865 represents a side elevation of part of a loom for weaving double pile fabrics. Thedrawing also illustrates one of the knife carriages with its actuating mechanism, and part ofthe sharpening mechanism adjacent to it with a part of its actuating mechanism. Fig. 866 is afront view of part of the…

Textile fabrics
