Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing (1890)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, S. Low, Marston · leaf 231

An illustration from Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing, 1890, leaf 231
s an end or cross-sectional elevation of the loom with the movable journal-boxesand crank-shaft thrown fully back, as when partially beating up the filling. Fig. 900 is a cross-sectional elevation of it without the gear-wheels, showing the journal-boxes and crank-shaft thrown forward and the lay…

Textile fabrics
