880^. RAILWAY PNEU-MATIC SIGNAL.—An aircylinder near the rail is operat-ed by the wheels passing uverthe lever A, pressing it againstthe cam S, on a rocking shaftB, lifting the plate C, and theconnected piston. Elevationand plan. 880^. A SELF REGIS-TERING TIDE GAUGE.—S is the float in the tide…
