Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing (1890)
Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, S. Low, Marston · leaf 263
e cards. 10. The Jacquard harness. In Fig. 999 we give a clear understanding of the principle of the construction of a Jacquardmachine by means of the sectional cut of one cross row in a 200 Jacquard machine, containing8 hooks, (representing an 8-row-deep machine), illustrating by it the… … filling. 251 hooks are held in their required places by the eyes of the needles (see place v at hook i) throughwhich the former are passed. The needles rest with their heads a to b, in the needle-board, extending outside, towards thecylinder, for about y2 inch. The rear part of the needle—the…
Textile fabrics
