Niaudet, Alfred, 1835-1883. [from old catalog], Fishback, L. M., [from old catalog] tr · New York, J. Wiley & sons · leaf 222
a cylinder of chloride of silver,AgCl, represented separately in the figure. To avoid an accidental contact of the two electrodes,the rod of chloride of silver is placed in a small cylinderof parchment paper, A ; there are two holes near the topof this paper cylinder, through which the strip of… … Fig. 46. 204 TWO-LIQUID BATTEEIES. The outside jar is closed with a paraffin stopper throughwhich the zinc passes ; the strip of silver passes betweenthe stopper and the glass jar. The figure also shows thatthere is a hole made in the paraffin stopper, throughwhich the liquid is poured in by means…
Electric batteries
