Tests of the pumps and wells of the University of Illinois (1914)

Lewis, John Edwin, Reilly, Raymond Thomas · leaf 36

An illustration from Tests of the pumps and wells of the University of Illinois, 1914, leaf 36 — are plottedin graph form on Plate 6. The rate of piston travel, which is di-rectly proportional to rate of discharge, as plotted against timeis shown graphically on Plate 7. TOTAL LIFT. The total lift is figured from the surfaceof the water to the point of discharge. To this is also added… … U. OF t. *. S. fO«M 3

Wells · Pumping machinery · Theses

Internet Archive · University of Illinois Urbana-Champaign · Public Domain Mark 1.0. Free to use for anything.
