A text book of elementary mechanics, for the use of colleges and schools (1881)
Dana, Edward Salisbury, 1849-1935 · New York, J. Wiley & sons · leaf 250
ame upward at d. That is, the weight is supported bythe four forces; viz., P + 2P + 2aP + 23P = 15P.Hence W = 15P = (24 - 1)P, or, in general, W = (2* - i)P. The tension on the beam is equal to TT + P, or 24P. 224. The following are other forms of pulleys, forwhich the relations of P to PFcan be… … Fig. 166. Fig. 167. 225. The Pulley on the Principle of Work. 1. SingleFixed Pulley. Here (Fig. 168) the power and weightact through equal distances; that is, s = % and there-fore W = P. 2. tfm^rfe Movable Pulley with Parallel Strings. In 232 STATICS. [175. this case (Figs. 169, 170) the distance…
