ssure, much more so than if the joint weremade horizontal, as at 6. These remarks will alsoapply to fig. 4, Plate 24. Problem 62. Fig. 4. To describe an Ogee Arch^ or an Arch of Contrary Flexure. Note.—^This arch is seldom used over a large opening, butoccurs frequently in canopies and tracery in…
