fig. 2. 3rd. If a cube be cut through the diagonals of threeadjoining faces, as in fig. 3, the section will be an equi-lateral triangle, whose side is equal to the diagonal ofa face of the cube. Two such sections may be madein a cube by cutting it again through the other threediagonals, and the… … lw.2.
