A text book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained (1849)

Minifie, William, 1805-1880 · Baltimore, W. Minifie & co. · leaf 49

An illustration from A text book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained, 1849, leaf 49 — Fig.4. Mg.5. … Yr^-Mira/U L ixMZUK iX J J^. PLATE VIII. 25 Application.—Problem 26. Fig. 2. To divide the Line E. F into any number of equal parts^ say 12. 1st. From E draw E, G at any angle to E. F, and step off withany opening of the dividers twelve equal spaces on E. G. 2nd. Join i^ 12, and with the parallel…

Mechanical drawing · Geometry, Descriptive · Perspective

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
