A text-book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained .. (1850)

Minifie, William, 1805-1880. [from old catalog] · Baltimore, W. Minifie & co. · leaf 218

An illustration from A text-book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained .., 1850, leaf 218
r perspectiveplane. 1st. Continue the sides of the plan to the perspective plane asshewn by the dotted lines, intersecting it in M. E. JV and O. 2nd. From the corners of the plan draw rays to the station point,intersecting the perspective plane in a. d. b. c. 3rd. Through S, draw S, F parallel to… … E a d 1> X c .rna/iKJcns plate lit. 105 Figure 2. 4th. Transfer these intersections from B. X^fig. 1; to J5. L^ fig. 2^and the vanishing points F and G to the horizon^ as shewn bythe dotted lines. 5th. From E and M, draw hnes to the vanishing point Gy andftom JV and 0^ draw Hnes to the vanishing…

Mechanical drawing · Geometry, Descriptive · Perspective
