A text-book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained .. (1850)

Minifie, William, 1805-1880. [from old catalog] · Baltimore, W. Minifie & co. · leaf 222

An illustration from A text-book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained .., 1850, leaf 222
s of the cottage^ for the tops and bottoms of the windows^the ridge and eaves of the roof^, and for the front of the chimney. Figure 2. Let us suppose the parallelogram P. L. W. K to he a separate pieceof paper laid on the other^ its top edge coinciding with the per-spective plane of fig. 1, and… … : V7 -iVT^MiTu/it. jTTian&Som PLATE LIU. 107 2nd. Draw H, K perpendicular to P, L for a line of heights. 3rd. Draw a line from K to the vanishing point without the pic-ture, which we will call Z; this will represent the line H. B of!fig. 1, continued indefinitely. 4th. From b and d draw…

Mechanical drawing · Geometry, Descriptive · Perspective
