A text-book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained .. (1850)

Minifie, William, 1805-1880. [from old catalog] · Baltimore, W. Minifie & co. · leaf 78

An illustration from A text-book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained .., 1850, leaf 78
Wj/,/y.<, .i.,if^-/,/.-:(./,/,. PLATE XV. 39 would be hexagonal, 8fc, The sides of all regular prisms areequal rectangular parallelograms. Fig. 5. Is a square pyramid^ bounded by a square at itsbase; and four regular triangles^ as shewn at fig. 6. Pyramids^ like prisms^ derive their names from…

Mechanical drawing · Geometry, Descriptive · Perspective

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
