A text-book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained .. (1850)

Minifie, William, 1805-1880. [from old catalog] · Baltimore, W. Minifie & co. · leaf 84

An illustration from A text-book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained .., 1850, leaf 84
W^.-MmOe,. Illm:nik.. 41 PLATE XVII. COVERINGS OF SOLIDSFig. 1. The Sphere Is a solid figure presenting a circular appearance when viewed inany direction; its surface is every where equidistant from a pointwithin^ called its centre. 1st. It may be formed by the revolution of a semicircle around…

Mechanical drawing · Geometry, Descriptive · Perspective
