Martin, Louis Adolphe, 1880- · New York : Wiley · leaf 93
Fig. 12, be negative and would indicate a loss of internal energyduring the change of state from {p\, vi) to {p, v). … Fig. 13. Exercise 87. Show that the construction illustrated in Fig.12 gives Aii: for the change of state from {pi, ih) to {p,v). GRAPHICS OF THE pV-PLANB 69 Graphical Representation of the Heat SuppHed.—The heat supplied during any change of state may be repre-sented by the area included between…
Mechanics
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
