A text-book of physics (1908)

Duff, A. Wilmer (Alexander Wilmer), b. 1864, ed, Guthe, Karl Eugen, 1866-1915, Hallock, William, 1857-1913, Lewis, E. Percival (Exum Percival), 1863-1925, Goodspeed, Arthur W. (Arthur Willis), b. 1860, Carman, Albert Pruden, b. 1861, McClung, Robert Kenning, 1874- · Philadelphia, P. Blakiston's Son & Co · leaf 615

An illustration from A text-book of physics, 1908, leaf 615
the primary current. The break in most coils is much quickerthan the make, and thus the direct induced E. M. F. in Sc is somuch greater than the inverse induced E. M. F., that the dis-charge effects are mostly uni-directional. The reason for thisis that the growth of the primary current at make is… … Fig. 44S. INDUCTION COILS. 597
