A text book of physics, for the use of students of science and engineering (1918)
Duncan, John, d. 1941, Starling, Sydney George, 1873- · London Macmillan · leaf 542
kwork flues are arranged roundthe boiler. The hot gases from the furnaces pass along the furnacetubes and emerge at the back end. Here they pass downwards intothe bottom flue E, and then along the bottom of the boiler to thefront end. At this end, the gases divide, and flow into two side flues mm… … 73 a> a i>fto ft© S a o 2 A boiler of this type can burn about 800 pounds of coal per hour,and can evaporate about 7000 pounds of water per hour. Theefficiency of a good boiler is about 75 per cent., i.e. about 75 out of 518 HEAT CHAP. every hundred heat units liberated from the burning fuel…Physics
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
