before fixing them in the wheel. At A, Fig. 238,the construction of the arms is shown, and at B the core prints,hubs and arms, with the manner of connecting these parts. After building up enough courses of segments to equal halfthe width of the rim plus half the thickness of the arms, the… … 5 So p. < s PATTERN MAKING 129 receive these ends are now cut into this half rim, and the arms fittedand glued in place but not so tightly as to strain the rim andcause it to spring after it is removed from the chuck. Theremaining courses for the rim are now fitted and glued on, and therim…
