A textbook on the locomotive and the air brake (1901)
International Correspondence Schools · Scranton, Pa., International textbook co · leaf 152
baremetal to the atmosphere; this prevents a great deal of thecondensation that would otherwise take place. This couplerwill couple with any straight-port coupler, and uncouplesautomatically. It presents a practically straight path tothe steam. The coupler used between engine and tender is the same… … Flu. 29. uncouple until this lever is put back. It will couple with theordinary coupler, the locking device not being brought into useunless desired. CAR EQUIPMENT: DIRECT STEAM. GENERAL, DESCRIPTION. 84. Fig. 30 illustrates the method of piping used in thedirect system of heating installed by the…
Locomotives · Locomotive boilers · Railroad cars
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
