A textbook on the locomotive and the air brake (1901)
International Correspondence Schools · Scranton, Pa., International textbook co · leaf 245
ction triple, auxiliary reservoir, brake cylinder, and connec-tions. A car drain cup is inserted in the train pipe; a branchpipe extending from this connects with the triple, as shown.In this branch pipe is a stop-cock ii, by means of which thebrake on that particular car can be cut out or cut in,…
Locomotives · Locomotive boilers · Railroad cars
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
