A textbook on mechanical and electrical engineering (1902)
International Correspondence Schools · Scranton : International Textbook Co. · leaf 55
40 GEOMETRICAL DRAWING §13 … Wither/ as a center, and A/as a radius, describe an arc///cutting the circumference at H. The chord A H is, one sideof the pentagon. Problem IT.—To inscribe a i*ea:iilar octaaron in a arivencircle. CoKSTRUCTiox.—In Fig. 50, from 6> as a center, with the dividers set to 1|, describethe circle…
